Bowman FH300-3282-2

Wholesale price for Bowman FH300-3282-2 ,

Introducing the Bowman FH300-3282-2 heat exchanger, specifically engineered for motors with a power output of up to 150 kW (201 HP). This exceptional device is compatible with various engine models, including the Ford BSD-678 and the Gardner 6LX.

The FH300-3282-2 features an inlet connection for raw water of 1-1/4″ BSP on one end and an identical outlet connection for raw water on the opposite end. Additionally, it includes a 57 mm connection for fresh water, ensuring it meets versatile engine cooling needs.

Bowman strongly advises against the installation of zinc anodes, as the heat exchanger’s tubes are crafted from a high-quality copper-nickel alloy that does not require such protection. Installing a zinc anode could compromise the natural copper oxide film that forms on the tubes, potentially exposing the material to corrosion over time.

Specifications:

• Raw water capacity: 1.55 liters
• Engine water capacity: 6.55 liters
• Header tank capacity: 4.12 liters
• Height: 275 mm (including pressure cap)
• Length: 472 mm
• Material: LM6M aluminum body, cupronickel tube stack, and composite end caps
• Maximum operating temperature: 100°C
• Width: 150 mm
• Brand: Bowman
• Compatible engines: Ford, Gardner
• Country of origin: United Kingdom
• Center-to-center mounting hole distance: 200 mm x 76 mm
• Maximum engine water pressure: 1 bar (depending on cap rating)
• Fixing hole size: M10 x 15
• Maximum power: 201 HP (150 kW)
• Inlet/outlet port size: Raw water inlet and outlet: 1-1/4″ BSP; Fresh water connection: 57 mm
• Model: FH300-3282-2
• Pressure rating: Cap: 10.8 PSI (0.75 Bar / 75 kPa)
• Maximum raw water flow: 125 liters per minute
• Maximum raw water pressure: 15 bar

This comprehensive description delivers essential information for boat owners seeking a reliable heat exchanger for their engines. The Bowman FH300-3282-2 is an optimal choice that guarantees performance, efficiency, and longevity.
