Capstan Quick THG 1000W 12v
€2.082,11
Out of stock
Wholesale price for Capstan Quick THG 1000W 12v ,
Introducing the Capstan Quick THG 1000W 12V, an exceptional solution designed to effortlessly recover boats or other loads without the hassle of using a rope. This capstan features a robust anodized aluminum base and drum, ensuring both durability and reliability.
It is equipped with a waterproof motor rated IP67, available in models of 1000W and 1500W, while the 500W model is fitted with a waterproof motor rated IP66. Additionally, the unit comes with a complete control box and a polymer cover for enhanced protection.
Key Features:
- Designed with a belt roller for efficient load recovery.
- Anodized aluminum base and drum for superior durability.
- IP67 waterproof motor for 1000W and 1500W models; IP66 for the 500W model.
- Reliable performance with anodized aluminum transmission.
- Includes a standard plastic cover for added protection.
Please note that the strap, available in sizes of 48 mm x 7.5 m or 48 mm x 10 m, must be ordered separately. An ISO8846 version, which offers ignition protection, is available upon request.
Specifications:
| Model | Power (W) | Voltage (V) | Max Drag (kg) | Working Load (kg) | Current Consumption @ Working Load (A) | Max Speed @ Working Load (m/min) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| THG500 | 500 | 12 | 1200 | 600 | 85 | 5.5 | 14 |
| THG1000 | 1000 | 12 | 1700 | 750 | 70 | 4.2 | 18.9 |
| THG1500 | 1500 | 12 | 2000 | 1000 | 108 | 5.5 | 18.9 |
This detailed overview of the Quick THG Capstan provides you with all the essential information you need to make an informed decision. If you have any further questions or require assistance, please do not hesitate to contact us.
| Weight | 20,00000000 kg |
|---|---|
| Dimensions | 500,00000000 × 500,00000000 × 500,00000000 cm |
