Spare Water Pump Dometic PMA1000C

Wholesale price for Spare Water Pump Dometic PMA1000C ,

PMA1000C Pump: This unique pump is specially designed for air conditioning systems with two or more units and a total cooling capacity exceeding 24,000 BTU/h (k = x1000), such as two T16 units. The PMA1000C operates at 230V and 50-60 Hz, delivering a remarkable flow rate of 12 GPM.

The robust Dometic Reliable centrifugal pump ensures a consistent flow of cooling water throughout the air conditioning system, enhancing performance and reliability.

For varied power environments, we offer a range of pumps and motors, all operating at 230V and 50/60Hz.

PML1000C Pump: This model features a magnetic impeller, achieving a flow rate of 1000 GPH, accommodating systems up to 48,000 BTU. The Dometic PML1000C/AC-5C-MD series 5 pumps are magnetic drive centrifugal pumps, eliminating the need for a mechanical shaft seal, which simplifies maintenance.

All models can be effortlessly maintained using just a screwdriver. The model abbreviations are as follows: C indicates a threaded inlet/outlet, A signifies a smooth inlet/outlet, and AC denotes air cooling.

Operation: These pumps are non-self-priming and do not provide suction lift, mandating flooded suction for effective operation. It is crucial to ensure that the pumps do not run dry, as the impeller requires the pumped liquid for lubrication. In applications involving liquids with a specific gravity greater than water, higher viscosity, or elevated temperatures, an adjusted impeller may be necessary.

Electrical: This model operates at 230 volts and comes with a 3-foot (0.9 m) power cord. The motors are U.L. listed and rated for continuous use.

Specifications:

• Flow rate: 1000 GPH
• Port size: 1″ FPT inlet and 1/2″ MPT outlet
• Maximum pressure: 50 PSI
• Maximum liquid temperature: 190°F
• Nominal voltage: 230V, 50/60 Hz
• Horsepower: 1/8

Invest in the reliability and performance of our Dometic pumps, essential for maintaining optimal air conditioning on your vessel!
